The Cisco 1000 Series Integrated Services Routers (ISR 1000 Series) portfolio has been steadily expanding over the years to provide our customers with the flexibility they need. The ISR 1000 Series combines routing, switching, Wi-Fi, integrated security, and DSL and LTE uplink connectivity options in a single, lightweight, high-performance device. Choose between the traditional Cisco IOS XE or controller-managed Cisco IOS XE SD-WAN software to deploy your network quickly and reliably on all Cisco ISR 1000 Series routers. With a simple and flexible pay-as-you-grow model, you purchase network capacity only when you need it.
Primary features and benefits – Cisco 113x ISRs
Table 1. Mechanical specifications for the Cisco 113x ISRs
|
Feature |
C1131(X)-8PW |
C1131(X)-8PLTEPW |
|
|
Dimensions (H x W x D) |
1.65 x 12.70 x 8.90 in. |
1.65 x 12.70 x 8.90 in. |
|
|
Weight |
4.78 lb. (2.17 kg) |
5.68 lb. (2.58 kg) |
|
|
Maximum power consumption |
25W |
31W |
|
|
External power supply |
|
||
|
Operating conditions |
|
||
|
Nonoperating conditions |
Temperature: -40° to +70°C (-40° to +158°F) Altitude: 0 to 15,000 ft (0 to 4572 m) Humidity: 5% to 95% relative humidity (noncondensing) |
||
|
Wi-Fi domains |
A, B, E, K, Q, or Z |
A, B, E, F, K, Q, or Z |
|
|
Minimum supported version (XE SD-WAN) |
17.7.1 |
17.7.1 |
|
Table 2. Cisco 113x ISR SKUs
|
Model |
WAN |
LAN |
||||
|
GE |
DSL |
5G |
LTE |
802.11ax |
GE |
|
|
C1131(X)-8PW* |
2 |
No |
No |
No |
Yes |
8 |
|
C1131(X)-8PLTEPW* |
2 |
No |
Yes |
Yes |
Yes |
8 |
